Imgix

{htmlwidgets} bindings for the imgix rendering API. Use images from the API in your {shiny} apps and {rmarkdown} documents.

Installation

This package can be installed directly from github using the {remotes} package

remotes::install_github("r-webutils/imgix-r")

Usage

Images can be defined with the imgix() function. You can either enter a full URL or an id from https://pexels.com.

library(imgix)
imgix(2339009)

imgix("https://images.unsplash.com/photo-1459478309853-2c33a60058e7")

API Parameters

API parameters can be passed directly to imgix(). Underscores are automatically converted to hyphens.

imgix(2422497, rot = 30)

imgix(1529360, txt = "Enjoy the rain", txt_size = 100, txt_color = "ddd",
       txt_align = "center,middle", blur = 20)

Shiny

Use renderImgix() to include images to your shiny application.

output$imgix <- renderImgix({
  imgix_as_widget(imgix(2339009))
})

The sizing must be defined in the corresponding output function imgixOutput().

Rendering Modes

This packages uses three different strategies to render images depending on the context.

Mode 1: htmlwidget

The default mode. The widget is shown using the {htmlwidgets} interface. Typical usecases are shiny applications and the rstudio viewer pane. Use imgix_as_widget() to directly generate the widget object.

widget <- imgix_as_widget(imgix(2339009))

Mode 2: html tag

The image is rendered to an html tag using the {htmltools} package. The htmltools::as.tag() generic is implemented and returns an <img> tag. This means that imgix objects can be embedded into tagLists and other ui definitions that are built with the {htmltools} package.

htmltools::div(
  imgix(2745224, mask = "ellipse", width = 400, height = 400),
  imgix('https://images.pexels.com/photos/45848/kumamoto-japan-aso-cloud-45848.jpeg',
        mask = "ellipse", width = 400, height = 400)
)

This mode is currently used for all html-based rmarkdown formats.

Mode 3: image file

The image is downloaded to a local image and referenced via a local path. For LaTeX-based rmarkdown formats. To directly download an image, use imgix_download()

imgix_download(imgix(2339009), file = "awesome_picture.jpeg")

Palette

imgix_palette() allows you to extract the most dominant colors from an image.

imgix_palette(2339009)

## [ imgixr color palette ]
## List of 3
##  $ average_luminance: num 0.261
##  $ colors           : chr [1:6] "#fede10" "#e53414" "#a78c6e" "#786578" ...
##  $ dominant_colors  : chr [1:6] "#fede10" "#abd5bc" "#57a5a5" "#0b4752" ...

Metadata

To get metadata about an image, use imgix_meta()

imgix_meta(2422497)

## [ imgix metadata ]
## List of 15
##  $ ColorModel    : chr "RGB"
##  $ Exif          :List of 38
##   ..$ SerialNumber            : chr "372051004311"
##   ..$ FocalPlaneXResolution   : int 1520
##   ..$ WhiteBalance            : int 0
##   ..$ CustomRendered          : int 0
##   ..$ ExposureProgram         : int 1
##   ..$ FlashCompensation       : int 0
##   ..$ SubsecTimeDigitized     : chr "22"
##   ..$ ExposureTime            : num 0.00625
##   ..$ DateTimeOriginal        : chr "2019:02:05 19:07:54"
##   ..$ BodySerialNumber        : chr "372051004311"
##   ..$ LensSpecification       :List of 4
##   .. ..$ : int 35
##   .. ..$ : int 35
##   .. ..$ : int 0
##   .. ..$ : int 0
##   ..$ MaxApertureValue        : int 1
##   ..$ PixelXDimension         : int 3154
##   ..$ ExposureBiasValue       : int 0
##   ..$ DateTimeDigitized       : chr "2019:02:05 19:07:54"
##   ..$ LensModel               : chr "35mm F1.4 DG HSM | Art 012"
##   ..$ LensID                  : int 368
##   ..$ ExposureMode            : int 1
##   ..$ ExifVersion             :List of 2
##   .. ..$ : int 2
##   .. ..$ : int 3
##   ..$ FNumber                 : num 1.8
##   ..$ SceneCaptureType        : int 0
##   ..$ ColorSpace              : int 1
##   ..$ LensSerialNumber        : chr "0000000000"
##   ..$ SensitivityType         : int 2
##   ..$ ImageNumber             : int 0
##   ..$ ISOSpeedRatings         :List of 1
##   .. ..$ : int 640
##   ..$ RecommendedExposureIndex: int 640
##   ..$ FocalPlaneResolutionUnit: int 3
##   ..$ ShutterSpeedValue       : num 7.32
##   ..$ Firmware                : chr "1.1.6"
##   ..$ SubsecTimeOriginal      : chr "22"
##   ..$ MeteringMode            : int 5
##   ..$ Flash                   : int 16
##   ..$ LensInfo                :List of 4
##   .. ..$ : int 35
##   .. ..$ : int 35
##   .. ..$ : int 0
##   .. ..$ : int 0
##   ..$ PixelYDimension         : int 3942
##   ..$ FocalLength             : int 35
##   ..$ ApertureValue           : num 1.7
##   ..$ FocalPlaneYResolution   : int 1520
##  $ Orientation   : int 1
##  $ Depth         : int 8
##  $ Output        : Named list()
##  $ Content-Type  : chr "image/jpeg"
##  $ JFIF          :List of 1
##   ..$ IsProgressive: logi TRUE
##  $ DPIWidth      : int 240
##  $ Content-Length: chr "9988613"
##  $ IPTC          :List of 4
##   ..$ DigitalCreationTime: chr "190754"
##   ..$ DigitalCreationDate: chr "20190205"
##   ..$ TimeCreated        : chr "190754"
##   ..$ DateCreated        : chr "20190205"
##  $ DPIHeight     : int 240
##  $ TIFF          :List of 9
##   ..$ ResolutionUnit           : int 2
##   ..$ Orientation              : int 1
##   ..$ Software                 : chr "Adobe Photoshop CS6 (Macintosh)"
##   ..$ YResolution              : int 240
##   ..$ DateTime                 : chr "2019:02:06 10:49:44"
##   ..$ Make                     : chr "Canon"
##   ..$ XResolution              : int 240
##   ..$ Model                    : chr "Canon EOS 6D"
##   ..$ PhotometricInterpretation: int 2
##  $ PixelWidth    : int 3154
##  $ PixelHeight   : int 3942
##  $ ProfileName   : chr "sRGB IEC61966-2.1"

More examples

The rendering API exposes a lot of parameters that can be used to modify images. All parameters to imgix() are directly sent as query parameters to the API. See https://docs.imgix.com/apis/rendering for the full API documentation.

imgix('https://ix-www.imgix.net/solutions/kingfisher.jpg',
       rect = '2100,600,1800,900')

imgix('https://assets.imgix.net/trim-ex4.jpg', monochrome = 787878)

imgix("https://images.unsplash.com/photo-1523712999610-f77fbcfc3843",
       duotone = "000080,FA8072")

imgix(1048273, fit = "clip")
